SSD Kingston mSATA 3 256GB
Original price was: 95 $.80 $Current price is: 80 $.
SSD KINGSTON mSATA 3 256GB
| SSD form factor | mSATA |
|---|---|
| SSD storage capacity | 256 GB |
| Interface | Serial ATA III |
| Memory type | 3D TLC |
| NVMe | |
| Component for | PC/notebook |
| Hardware encryption | |
| Security algorithms | 256-bit AES-XTS |
| Data transfer rate | 6 Gbit/s |
| Read speed | 550 MB/s |
| Write speed | 500 MB/s |
| Random read (4KB) | 90000 IOPS |
| Random write (4KB) | 80000 IOPS |
| Controller type | SMI SM2259 |
| Mean time between failures (MTBF) | 1000000 h |
| TBW rating | 150 |
| Harmonized System (HS) code | 84717070 |
Power
| Power consumption (read) | 1.2 W |
|---|---|
| Power consumption (write) | 2.4 W |
| Power consumption (average) | 0.1 W |
| Power consumption (idle) | 0.08 W |
Related products
Enclosure SSD Msata USB 3.0
ENCLOSURE SSD MSATA USB 3.0
- Transfer rates up to 6Gb/s
- mSATA enclosure for turning any mSATA SSD into a portable USB storage device
- Hot-swappable, plug and play, no drivers needed
- Backwards compatible with USB 2.0 or 1.1, this enclosure is a perfect solution for data transfers or data backup
- Material: Aluminum alloy, Size: 7.2 * 4.2 * 1.2cm / 2.83 * 1.65 * 0.47in (L * W * H)
SSD Kingston 2.5″ SATA 3 480GB
SSD KINGSTON 2.5" SATA 3 480GB
Form factor 2.5” & M.2 2280
Interface SATA Rev. 3.0 (6Gb/s) – with backwards compatibility
to SATA Rev. 2.0 (3Gb/s)
Capacities2 120GB, 240GB, 480GB, 960GB
Baseline performance1
Data transfer (ATTO)
120GB — up to 500MB/s read and 320MB/s write
240GB — up to 500MB/s read and 350MB/s write
480GB — up to 500MB/s read and 450MB/s write
960GB — up to 500MB/s read and 450MB/s write
Power consumption 0.195W idle / 0.279W avg / 0.642W (MAX)
read / 1.535W (MAX) write
Storage temperature -40°C~85°C
Operating temperature 0°C~70°C
Dimensions 100.0mm x 69.9mm x 7.0mm (2.5”)
80mm x 22mm x 1.35mm (M.2)
Weight 39g (120GB – 2.5”)
41g (240-480GB – 2.5”)
41.9g (960GB – 2.5”)
6.7g (256GB – M.2)
5.5g (480GB – M.2)
Vibration operating 2.17G peak (7-800Hz)
Vibration non-operating 20G peak (10-2,000Hz
SSD Kingston SATA 3 1TB
SSD KINGSTON SATA 3 1TB
Form Factor: mSATA
Interface: SATA Rev. 3.0 (6Gb/s) – with backwards capability to SATA Rev 2.0 (3Gb/s)
Capacities2: 256GB, 512GB, 1024GB
Controller: SM2259
NAND: 3D TLC
Encrypted: XTS-AES 256-bit encryption
Sequential Read/Write1: 256GB — up to 550/500MB/s, 512GB – 1024GB — up to 550/520MB/s
Maximum 4K Read/Write1: up to 90,000/80,000 IOPS
Power Consumption: 0.08W Idle / 0.1W Avg / 1.2W (MAX) Read / 2.4W (MAX) Write
Dimensions: 50.8mm x2 9.85mm x 4.85mm
Weight: 7g
